Mother board

X11DDW-NT

• 2nd Gen Intel® Xeon® Scalable Processors and Intel® Xeon® Scalable Processors, Dual Socket LGA-3647 (Socket P) supported, CPU TDP support Up to 205W TDP, 2 UPI up to 10.4 GT/s

• Intel® C622

• Up to 3TB 3DS ECC RDIMM, DDR4-2933MHz; Up to 3TB 3DS ECC LRDIMM, DDR4-2933MHz, in 12 DIMM slots;Up to 2TB Intel® Optane DC Persistent Memory in memory mode (Cascade Lake only).

• 1 PCI-E 3.0 x32 Left Riser Slot,1 PCI-E 3.0 x16 Right Riser Slot,1 PCI-E 3.0 x16 for Add-On-Module (AOM)M.2 Interface: PCI-E 3.0 x4M.2 Form Factor: 2242, 2260, 2280, 22110M.2 Key: M-KeyU.2 Interface: PCI-E 3.0 x4,4 PCI-E 3.0 NVMe x4 Internal Port(s)

• 1 VGA port

• Intel® C622 controller for 14 SATA3 (6 Gbps) ports; RAID 0,1,5,10

• Dual LAN with 10Gbase-Tfrom C622

Learn more →
X11DDW-L

• 2nd Gen Intel® Xeon® Scalable Processors and Intel® Xeon® Scalable Processors, Dual Socket LGA-3647 (Socket P) supported, CPU TDP support Up to 205W TDP, 2 UPI up to 10.4 GT/s

• Intel® C621

• Up to 3TB 3DS ECC RDIMM, DDR4-2933MHz; Up to 3TB 3DS ECC LRDIMM, DDR4-2933MHz, in 12 DIMM slots;Up to 2TB Intel® Optane DC Persistent Memory in memory mode (Cascade Lake only)

• 1 PCI-E 3.0 x32 Left Riser Slot,1 PCI-E 3.0 x16 Right Riser Slot,1 PCI-E 3.0 x16 for Add-On-Module (AOM)M.2 Interface: PCI-E 3.0 x4M.2 Form Factor: 2242, 2260, 2280, 22110M.2 Key: M-Key

• 1 VGA port

• Intel® C621 controller for 14 SATA3 (6 Gbps) ports; RAID 0,1,5,10

• Dual LAN with GbEfrom C621

Learn more →
X11SSW-TF

• Single socket H4 (LGA 1151) supports Intel® Xeon® processor E3-1200 v6/v5, Intel® 7th/6th Gen. Core™ i3 series,Intel® Celeron® and Intel® Pentium®

• Intel® C236 chipset

• Up to 64GB Unbuffered ECC UDIMM DDR4 2400MHz; 4 DIMM slots

• Intel® X540 Dual port 10GBase-T

• Support Intel® VHD with selected CPU

• 6 SATA3 (6Gbps) via C236; RAID 0, 1, 5, 10

• I/O: 1 VGA, 2 COM, TPM header

• 5 USB 3.0 (2 rear, 2 via header(s), 1 Type A), 6 USB 2.0 (2 rear, 4 via header(s))

• 2 SuperDOM with built-in power

• M.2 NGFF connectorM.2 Interface: PCI-E 3.0 x4Form Factor: 2260, 2280, 22110Key: M-Key Double Height Connector

Learn more →
Global Sku

X11SSW-F

• Single socket H4 (LGA 1151) supports Intel® Xeon® processor E3-1200 v6/v5, Intel® 7th/6th Gen. Core i3 series,Intel® Celeron® and Intel® Pentium®

• Intel® C236 chipset

• Up to 64GB Unbuffered ECC UDIMM DDR4 2400MHz; 4 DIMM slots

• Expansion slots:1 PCI-E 3.0 x4(in x16, Right Riser slot),1 PCI-E 3.0 x16 (Left Riser slot)

• Dual GbE LAN with Intel® i210-AT

• 6 SATA3 (6Gbps) via C236; RAID 0, 1, 5, 10

• I/O: 1 VGA, 2 COM, TPM header

• 2 SuperDOM with built-in power

• 5 USB 3.0 (2 rear, 2 via header(s), 1 Type A), 6 USB 2.0 (2 rear, 4 via header(s))

• M.2 NGFF connectorM.2 Interface: PCI-E 3.0 x4 and SATAForm Factor: 2260, 2280, 22110Key: M-Key Double Height Connector

Learn more →
X11SSW-4TF

• Single socket H4 (LGA 1151) supports Intel® Xeon® processor E3-1200 v6/v5, Intel® 7th/6th Gen. Core™ i3 series,Intel® Celeron® and Intel® Pentium®

• Intel® C236 chipset

• Up to 64GB Unbuffered ECC UDIMM DDR4 2400MHz; 4 DIMM slots

• Quad LAN w/ Intel® X540 10GBase-T

• Support Intel® VHD with selected CPU

• 6 SATA3 (6Gbps) via C236; RAID 0, 1, 5, 10

• I/O: 1 VGA, 2 COM, TPM header

• 5 USB 3.0 (2 rear, 2 via header(s), 1 Type A), 6 USB 2.0 (2 rear, 4 via header(s))

• 2 SuperDOM with built-in power

• M.2 NGFF connectorM.2 Interface: PCI-E 3.0 x4Form Factor: 2260, 2280, 22110Key: M-Key Double Height Connector

Learn more →
X11SSM-F

• Single socket H4 (LGA 1151) supports Intel® Xeon® processor E3-1200 v6/v5, Intel® 7th/6th Gen. Core™ i3 series,Intel® Celeron® and Intel® Pentium®

• Intel® C236 chipset

• Up to 64GB Unbuffered ECC UDIMM DDR4 2400MHz; 4 DIMM slots

• Expansion slots:1 PCI-E 3.0 x8 (in x16),1 PCI-E 3.0 x8,2 PCI-E 3.0 x4 (in x8)

• Dual GbE LAN with Intel® i210-AT

• 8 SATA3 (6Gbps) via C236;RAID 0, 1, 5, 10

• I/O: 1 VGA, 2 COM, 2 SuperDOM, and TPM header

• 5 USB 3.0 (2 rear, 2 via header(s), 1 Type A), 6 USB 2.0 (2 rear, 4 via header(s))

• Integrated IPMI 2.0 and KVM with Dedicated LAN

Learn more →
X11SSM

• Single socket H4 (LGA 1151) supports Intel® Xeon® processor E3-1200 v6/v5, Intel® 7th/6th Gen. Core i3 series,Intel® Celeron® and Intel® Pentium®

• Intel® C236 chipset

• Up to 64GB Unbuffered ECC UDIMM DDR4 2400MHz; 4 DIMM slots

• Expansion slots:1 PCI-E 3.0 x8 (in x16),1 PCI-E 3.0 x8,2 PCI-E 3.0 x4 (in x8)

• Dual GbE LAN with Intel® i210-AT

• 8 SATA3 (6Gbps) via C236; RAID 0, 1, 5, 10

• I/O: 1 VGA, 2 COM, 2 SuperDOM, and TPM header

• 5 USB 3.0 (2 rear, 2 via header(s), 1 Type A), 6 USB 2.0 (2 rear, 4 via header(s))

Learn more →
X11SSL-nF

• Single socket H4 (LGA 1151) supports Intel® Xeon® processor E3-1200 v6/v5, Intel® 7th/6th Gen. Core™ i3 series, Intel® Celeron® and Intel® Pentium®

• Intel® C232 chipset

• Up to 64GB Unbuffered ECC UDIMM DDR4 2400MHz; 4 DIMM slots

• Expansion slots:
1 PCI-E 3.0 x8 (in x16),
1 PCI-E 3.0 x4 (in x8),
1 PCI-E 3.0 x1

• Dual GbE LAN with Intel® i210-AT

• 6 SATA3 (6Gbps) via C232; RAID 0, 1, 5, 10

• 2 PCI-E 3.0 x4 NVMe External Ports

• I/O: 1 VGA, 2 COM, TPM header

• 2 SuperDOM with built-in power

• 5 USB 3.0 (2 rear, 2 via header(s), 1 Type A), 6 USB 2.0 (2 rear, 4 via header(s))

Learn more →
Global Sku

X11SSL-F

• Single socket H4 (LGA 1151) supports Intel® Xeon® processor E3-1200 v6/v5, Intel® 7th/6th Gen. Core™ i3 series, Intel® Celeron® and Intel® Pentium®

• Intel® C232 chipset

• Up to 64GB Unbuffered ECC UDIMM DDR4 2400MHz; 4 DIMM slots

• Expansion slots:
1 PCI-E 3.0 x8 (in x16),
1 PCI-E 3.0 x8,
1 PCI-E 3.0 x4 (in x8)

• Dual GbE LAN with Intel® i210-AT

• 6 SATA3 (6Gbps) via C232; RAID 0, 1, 5, 10

• I/O: 1 VGA, 1 COM, TPM header

• 2 SuperDOM with built-in power

• 5 USB 3.0 (2 rear, 2 via header(s), 1 Type A), 6 USB 2.0 (2 rear, 4 via header(s))

• Integrated IPMI 2.0 and KVM with Dedicated LAN

Learn more →
X11SSL-CF

• Single socket H4 (LGA 1151) supports Intel® Xeon® processor E3-1200 v6/v5, Intel® 7th/6th Gen. Core™ i3 series, Intel® Celeron® and Intel® Pentium®

• Intel® C232 chipset

• Up to 64GB Unbuffered ECC UDIMM DDR4 2400MHz; 4 DIMM slots

• Expansion slots:
1 PCI-E 3.0 x8 (in x16),
1 PCI-E 3.0 x4 (in x8),
1 PCI-E 3.0 x1

• Dual GbE LAN with Intel® i210-AT

• 6 SATA3 (6Gbps) via C232; RAID 0, 1, 5, 10

• 8 SAS3 (12Gbps) via Broadcom® 3008 SW controller; RAID 0, 1, 10

• I/O: 1 VGA, 2 COM, TPM header

• 2 SuperDOM with built-in power
5 USB 3.0 (2 rear, 2 via header(s), 1 Type A), 6 USB 2.0 (2 rear, 4 via header(s))

Learn more →
X11SSL

• Single socket H4 (LGA 1151) supports Intel® Xeon® processor E3-1200 v6/v5, Intel® 7th/6th Gen. Core™ i3 series, Intel® Celeron® and Intel® Pentium®

• Intel® C232 chipset

•Up to 64GB Unbuffered ECC UDIMM DDR4 2400MHz; 4 DIMM slots

• Expansion slots:
1 PCI-E 3.0 x8 (in x16),
1 PCI-E 3.0 x8,
1 PCI-E 3.0 x4 (in x8)

• 6 SATA3 (6Gbps) via C232; RAID 0, 1, 5, 10

• I/O: 1 VGA, 1 COM, TPM header

• 2 SuperDOM with built-in power

• 5 USB 3.0 (2 rear, 2 via header(s), 1 Type A), 6 USB 2.0 (2 rear, 4 via header(s))

Learn more →
X11SSi-LN4F

• Single socket H4 (LGA 1151) supports Intel® Xeon® processor E3-1200 v6/v5, Intel® 7th/6th Gen. Core™ i3 series, Intel® Celeron® and Intel® Pentium®

• Intel® C236 chipset

• Up to 64GB Unbuffered ECC UDIMM DDR4 2400MHz; 4 DIMM slots

• Expansion slots:
1 PCI-E 3.0 x8 (in x16),
1 PCI-E 3.0 x8,
1 PCI-E 3.0 x4 (in x8)

• Quad GbE LAN with Intel® i210-AT

• 6 SATA3 (6Gbps) via C236; RAID 0, 1, 5, 10

• I/O: 1 VGA, 2 COM, TPM header

• 2 SuperDOM with built-in power

• 5 USB 3.0 (2 rear, 2 via header(s), 1 Type A), 6 USB 2.0 (2 rear, 4 via header(s))

• M.2 NGFF connector
M.2 Interface: PCI-E 3.0 x4 and SATA
Form Factor: 2242, 2260, 2280, 22110
Key: M-Key
Double Height Connector

Learn more →
